ADJ Focus Spot 7Z

• 420W White LED Engine
• 20,000 Hour Average LED Life

Photometric Data

• 20,000 Total Lumens
• 8,000K, >73CRI (without CRI Filter)
• 7,700K >85CRI (with CRI Filter)
• 56,513 LUX @16.4’ (5m) (6° Beam)
• 1,585 LUX @16.4’ (5m) (48° Beam)

Effects

• 4-Facet Circular & 6-Facet Linear Rotating Prisms
• 2 Frost Filters (Light & Heavy)
• Animation Wheel (Rotatable and Indexable)
• Motorized Zoom (6° ~ 48°)
• Motorized Focus
• Motorized Iris
• Electronic Dimming & Strobe (1-20Hz)

Color

• Full CMY color mixing
• Variable CTO (2,700K to 8,000K)
• Colors Wheel with 7 dichroic slots (Includes High CRI and CTB Filters)
• CMY and Color Wheel preset macros

Gobos

• (2) Gobo Wheels
• #1 - (7) Interchangeable Rotating-Indexing Glass Gobos
• #2 - (7) Interchangeable Rotating-Indexing Glass Gobos

Control / Connections

• (3) DMX Channel Modes (30 / 34 / 45)
• DMX512, ArtNet and sACN protocols
• WiFly EXR Wireless DMX
• RDM (Remote Device Management) compliant
• 6 Button Touch Control Panel
• Full Color 180° Reversible LCD Menu Display
• 8 / 16 Bit Resolution Adjustable Movement
• 5-pin XLR DMX In/Out
• Locking In/Out power connections

Pan / Tilt

• Pan: 540-degrees
• Tilt: 270-degrees
• Pan & Tilt Locks

Dimensions & weight

• Dimensions (WxDxH): 374x234x630 mm
• Weight: 51.7 lbs. (23.45kg)

Electrical & Thermal

• AC 100-240V - 50/60Hz
• Max Power Consumption: 524W
• Max ambient temperature: 14°F to 113°F (-10°C to 45°C)
• Max housing temperature: 136°F (58°C)

Technical data

• DB Rating @ 3ft.: 49dB
• BTU: 0.53
• BTU/H: 1,909.60

Approvals & Ratings

• CE | ETL (Pending)
• IP20

Included accessories

• Locking Power cable
• 180mm Omega brackets (x2)
